2244L 21.5" Open Frame Touchscreen (Discontinued August 2013)
Overview
The Elo Touch Solutions 2244L open-frame LCD touchmonitor with its slim design and narrow outside dimensions gives kiosk integrators an edge in developing the most aesthetically pleasing products. Wide-aspect displays like the Elo 2244L are easier to use and incorporate than traditional open-frame touchmonitors. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in casino gaming, amusement and entertainment settings and are increasingly popular in public venue environments due to the high-definition cinematic-like experience. Typical applications for the 2244L include: gaming and amusement, information kiosks and self-service, as well as interactive digital signage applications.
State-of-the-art LED backlighting used in the 2244L makes the panel thinner overall as the cold cathode fluorescent lights (CCFL) are replaced with LED lights. LED lights also take less electricity to operate and generate less heat. This leads to the slimmer dimensions of the 2244L that facilitate OEMs and system integrators the flexibility to design aesthetically pleasing and stylish kiosks.
Available with IntelliTouch, IntelliTouch Plus, standard bezel surface acoustic wave, as well as IntelliTouch Zero-Bezel SAW and IntelliTouch Pro projected capacitive touchscreen technology for a true flat look,, the 2244L provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response and vivid images. Projected capacitive provides a durable, zero-bezel, glass-to-edge surface with multi-touch, while surface acoustic wave is the optical standard of touch and widely used in kiosk and gaming applications. Both are pure glass constructions to deliver a clear, bright and long-lasting performance and it also makes the touchscreens scratch-resistant. It is nearly impossible to physically "wear out" these touchscreens.
Features
- Slimmer dimensions enables thinner, artistic enclosure designs
- Multi-touch, dual-touch and single touch options available
- High definition LCD display offers ultimate HD interactivity, clarity and resolution
- Portrait and landscape mode possible
- IntelliTouch Pro projected capacitive passes ball-drop impact testing to IK07 and UL 60950 standards and offers four touch points (HID)
- Viewing angle of 178°(h) × 178°(v), wider than most 22” touchmonitors, allows colors to remain sharp and graphics to retain their integrity in both portrait and landscape modes
- 16:9 aspect ratio and bright 250 nits panel for a larger display surface and bright vivid images
- LED backlighting allows for state-of-the-art slim design while reducing power consumption
- Optimized for use in high-traffic environments
- Three year warranty
Especificações
-
Técnico
Modelos
APR (Antiglare, Worldwide) - E738068
Cor do Monitor
Preto
Tecnologia do Touch
Reconhecimento de Pulso Acústico - Single Touch
Interface do touch
USB
Tamanho da diagonal
21,5'' diagonais, LCD (LED) TFT matriz ativa
Visualização na tela (OSD)
Controls: Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Source
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Accessible through switches on the unit's tethered OSD Control Box.Proporção da tela
16:9
Área ativa
18.7" x 10.5" / 475 mm x 267 mm
Resolução
1920x1080
Outras resoluções suportadas
640x480 60Hz
720x576 50Hz
800x600 56, 60Hz
1024x768 60Hz
1280x720 50, 0Hz
1280x960 60Hz
1280x1024 60Hz
1366x768 60Hz
1440x900 60Hz
1680x1050 60Hz
1920x1080 50, 60HzÂngulo de visão
Horizontal: ±89° ou 178° total / Vertical: ±89° ou 178° total
Número de cores
16.7 milhões
Brilho (típico)
LCD panel: 250 nits
Tempo de resposta (típico)
14 msec
Razão de contraste
1000:1
Formato da entrada de vídeo
Analog VGA, DVI-D
Entrada do conector dos sinais de vídeo
Analog VGA on Female DE-15 connector; Digital on Female DVI-D connector
Fonte de alimentação
External DC - Optional power brick (sold separately)
Conector da entrada do monitor
Type: DC Barrel Jack
Barrel inner diameter: 6.4mm (+/- 0.3mm)
Pin outer diameter: 2.0mm (+0.0 -0.1mm)
Input voltage range: +12VDC ±5%Conector da entrada da fonte de alimentação
Type: IEC 60320 C14
Adapter input voltage range: 100-240VAC, 50/60HzTensão de entrada
+12VDC ±5%
Conector de entrada
DC Barrel Jack
Frequência de entrada
Horizontal: 31.5-80 kHz
Vertical: 50-75 HzConsumo de energia (típico)
ON (monitor only): 26W
ON (monitor + AC/DC adapter at 230V/50Hz): 39W
SLEEP (monitor + AC/DC adapter at 230V/50Hz): 1.5W
OFF (monitor + AC/DC adapter at 230V/50Hz): 1.0WDimensões
Please reference the dimensional drawing
Dimensões da Caixa
7.87" x 16.93" x 24.41" / 200 mm x 430 mm x 620 mm
Peso (sem embalagem)
10.6 lbs / 4.8 kg
Peso (embalado)
15.3 lbs / 7.0 kg
Temperatura de operação
0°C to 40°C / 32°F to 104°F
Temperatura de armazenamento
-20°C to 60°C / -4°F to 140°F
Umidade
Operating: 20%-80% Storage: 10%-90%
MTBF - Tempo médio entre falhas
50.000 horas demonstradas
Garantia
3 anos
Aprovações e declarações reguladoras
S-Mark, C-Tick, cUL, IC, CCC, CE, VCCI, KCC, Mexico CoC, Taiwan BSMI, UL, FCC, International CB
RoHS, China RoHS, WEEE, IMERCOpções de montagem
VESA 4-hole 100mm mounting interface on rear of unit
2-hole mounting interface on all 4 sides
See dimensional drawings for detailsOpções / Periféricos / Upgrades
OSD remoto (RJ45) - Elo P/N: E483757
Kit de cabos sobressalente - Elo P/N: E378229
Fonte de alimentação e kit de cabos para norteamericana - Elo P/N: E005277
Fonte de alimentação e kit de cabos para europeia e coreana - Elo P/N: E571601
Fonte de alimentação e kit de cabos para Reino Unido - Elo P/N: E180092
Fonte de alimentação e kit de cabos para chinesa - Elo P/N: E558862
Fonte de alimentação e kit de cabos para taiwanesa - Elo P/N: E818655
Fonte de alimentação e kit de cabos para japonesa - Elo P/N: E182546
Fonte de alimentação e kit de cabos para argentina - Elo P/N: E887099
Caneta stylus IntelliTouch - Elo P/N: D82064-000
Suporte de montagem de rack Elo 22” - Elo P/N: E462672
Bezel de montagem frontal Elo 22” de largura - Elo P/N: E668194
Elo 22 polegadas - Suporte em L wide - Elo P/N: E530432Caneta stylus IntelliTouch opcional
Stylus pen with rubber tip, designed specifically for use with IntelliTouch surface wave touch technology. Part number D82064-000, available at additional cost
